Function Generator – TEKTRONIX AFG1000
Price: Contact
In stock
- Description
- References
- Remarks
Product Specifications and Features:
- Frequency Range: 1 μHz – 25/60MHz
- Channels: 1/2
- Amplitude flatness: ±0.4 dB
- Harmonic distortion: < -60 dBc
- Total harmonic distortion: < 0.2%
- Spurious: < -45 dBc
- Phase noise: 1 MHz: < -110 dBc/Hz @ 10 kHz offset
- Pulse wave: 1 μHz to 12.5/30 MHz
- Rise/fall time: <12 ns
- Arbitrary waveform: 1 μHz to 10/30 MHz
- Memory Length: 8 Kpoint
- Sampling rate: 125/300 MS/s
- Amplitude: 1 mVp-p – 10 Vp-p
- Resolution: 1 mVp-p, 1 mVrms
- Modulation: AM, FM, PM, FSK, PWM
- Interface: USB
- Display: 3.95-inch
- Power: 220-240 VAC, 100-120 VAC, 50/60 Hz
- Operating Temperature: 0 ℃ to 40 ℃
- Integrated Function: N/A
