Function Generator – T3AFG Series
Price: Contact
In stock
- Description
- References
- Remarks
Product Specifications and Features:
- Frequency Range: 1 μHz – 30/60 MHz
- Channels: 1/2
- Amplitude flatness: ±0.3 dB
- Harmonic distortion: <- 50 dBc
- Total harmonic distortion: 0.075 %
- Spurious: <- 55 dBc
- Phase noise: N/A
- Pulse wave: 1 μHz – 12.5 MHz
- Rise/fall time: 16.8 ns
- Arbitrary waveform: 1 μHz – 6 MHz
- Memory Length: 16 k points
- Sampling rate: 30 MSa/s
- Amplitude: 2 mV – 10 Vpp
- Resolution: 1mV
- Modulation: AM, DSB-AM, FM, PM, FSK, ASK, PSK, PWM
- Interface: USB
- Display: 4.3″
- Power: 100 V to 240 V (+/-10 %) at 50 Hz / 60Hz
- Operating Temperature: 0 ℃ to 40 ℃
- Integrated Function: N/A
